Snorkel SL26RT Sigma Boom Lift – Climb gradient upto 50 degrees!

Description

The Snorkel SL26RT Speed Level is the original sigma boom lift. Climbing gradients up to 50% and featuring automatic self-levelling without outriggers, it offers superior stability. This Speed Level also features an extension deck for additional outreach. With superb ground clearance and powerful 4-wheel drive, the SL26RT can handle any jobsite.

STANDARD FEATURES

• Automatic powered platform levelling
• Powerful 4 wheel drive
• Oscillating front axle
• Roll-out deck extension
• Descent alarm
• High grip, all-terrain tires
• Dual multi-disc brakes
• Proportional controls
• Flashing amber light
• Power line to platform
• Fold-down guardrails
• All motion alarm
• Hour meter & on-board diagnostics display
• Horn
• 2 year parts & labour, 5 year structural warranty

• Specifications
• Max Working Height: 10.0m
• Max Platform Height: 8.0m
• Platform Size (Stowed): 1.72m x 3.66m
• Platform Size (Extended): 1.72m x 4.6m
• Extension Deck Length: 0.91m
• Overall Width: 2.13m
• Overall Length: 3.79m
• Stowed Height: 2.6m
• Min Height (Guardrails Folded): 1.7m
• Chassis Ground Clearance: 305mm
• Axle Ground Clearance: 195mm
• Platform Capacity (SWL): 680kg
• Max Drive Height: 8.0m
• Max Wind Speed: 12.5m/s
• Max Drive Speed (Stowed): 6.4km/h
• Max Drive Speed (Elevated): 0.8km/h
• Raise/Lower Time: 21/32 seconds
• Gradeability: 50%
• Max Levelling (Front to Rear): 9°
• Max Levelling (Side to Side): 13°
• Inside Turning Radius: 3.9m
• Outside Turning Radius: 5.64m
• Tyres: 26 x 12.00 – 12 Foam Filled
• Controls: Proportional Joystick
• Drive System: 4 Wheel Drive with Hydraulic Motors and Flow Dividers
• Power Source: Kubota D-902 Water-Cooled Diesel, Tier 4 Final
• Weight: 3,500kg

With 20+ years of experience, Equipment Sales Australia offers top-quality construction equipment at competitive prices. We provide expert advice, reliable brands, and a network of service providers to ensure long-term performance. Contact us today for the best solutions!

Technical Specifications

• Condition

  New

• Year

  Not specified

• Make

  Snorkel

• Drive Type

  Wheeled 4wd

• Max Working Height

  10.0m

• Max Platform Height

  8.0m

• Platform Size (Stowed)

  1.72m x 3.66m

• Platform Size (Extended)

  1.72m x 4.6m

• Extension Deck Length

  0.91m

• Overall Width

  2.13m

• Overall Length

  3.79m

• Stowed Height

  2.6m

• Min Height (Guardrails Folded)

  1.7m

• Chassis Ground Clearance

  305mm

• Axle Ground Clearance

  195mm

• Platform Capacity (SWL)

  680kg

• Max Drive Height

  8.0m

• Max Wind Speed

  12.5m/s

• Max Drive Speed (Stowed)

  6.4km/h

• Max Drive Speed (Elevated)

  0.8km/h

• Raise/Lower Time

  21/32 seconds

• Gradeability

  50%

• Max Levelling (Front to Rear)

  9°

• Max Levelling (Side to Side)

  13°

• Inside Turning Radius

  3.9m

• Outside Turning Radius

  5.64m

• Tyres

  26 x 12.00 – 12 Foam Filled

• Controls

  Proportional Joystick

• Drive System

  4 Wheel Drive with Hydraulic Motors and Flow Dividers

• Power Source

  Kubota D-902 Water-Cooled Diesel, Tier 4 Final

• Weight

  3,500kg
